Molecular Sieve 13X is the sodium form of the type X crystal and has a much larger pore opening than the type A crystals. It will adsorb molecules with a kinetic diameter of less than 9 Angstrom (0.9nm) and exclude molecules of larger than 0.9nm.
It is commonly used to separate nitrogen from oxygen. Since it also has the highest theoretical capacity of the common adsorbents and very good mass transfer rates. it usually used as carrier for catalysts.
Recommendation
1. Removal of CO2 and moisture from air (air pre-purification) and other gases.
2. Separation of enriched oxygen from air.
3. Removal of mercaptans and hydrpogen sulphide from hydrocarbon liquid streams such as LPG, butane, propane etc.
4. Catalyst protection, removal of oxygenates from hydrocarbons (olefin streams)
5. Removal of n-chained compositions from aromatics
Technical Specification
| Property | Unit | 8X12 | 4X8 | 1/16” | 1/8” |
| Diameter | mm | 1.6-2.5 | 3-5 | 1.5-1.8 | 2.8-3.2 |
| Static H2O Adsorption | wt% | ≥26.00 | ≥26.00 | ≥26.00 | ≥26.00 |
| Static CO2 Adsorption | wt% | ≥17.50 | ≥17.50 | ≥17.50 | ≥17.50 |
| Bulk Density | g/ml | ≥0.62 | ≥0.62 | ≥0.62 | ≥0.62 |
| Crush strength | N | ≥30.00 | ≥80.00 | ≥30.00 | ≥70.00 |
| Loss on ignition | wt% | ≤1.50 | ≤1.50 | ≤1.50 | ≤1.50 |
| Loss on Attrition | wt% | ≤0.10 | ≤0.10 | ≤0.30 | ≤0.30 |
| Type | Carton | Drum | Super sack |
| Bead | 25 kg / 55 lb | 150 kg / 330 lb | 1000kg / 2200 lb |
| Pellet | 25 kg / 55 lb | 150 kg / 330 lb | 1000kg / 2200 lb |
