Since the non-zeolite binder of common molecular sieve 5A is transferred to zeolite, binderless 5A has special characteristics such as greater CO, N2 and CH4 adsorption capacity. Most of the time, binderless 5A works with activeted carbon in a pressure swing system (PSA). By PSA method, the hydrogen purity can reach 99.9999%. Until now, it is the most commonly used adsorbents in hydrogen purification with PSA method.
Binderless 5A N2 and CO adsorption isotherm
Recommendation
Hydrogen purification by PSA method.
Technical Specification
| Property | Unit | 8X12 |
| Diameter | mm | 1.6-2.5 |
| Static Water Adsorption | wt% | ≥24.00 |
| N2 Adsorption | ml/g | ≥10.00 |
| CO Adsorption | ml/g | ≥26.00 |
| Bulk Density | g/ml | ≥0.70 |
| Crush Strength | N | ≥25 |
| Loss on Ignition | wt% | ≤1.50 |
CAS NO.: 1318-02-1
EC NO.: 215-283-8
REACH: 01- 2119429034- 49- XXXX
Packing
| Type | Drum | Super sack |
| Bead | 150 kg / 330 lb | 1000kg / 2200 lb |
| Pellet | 150 kg / 330 lb | 1000kg / 2200 lb |
